Somfy Levixo 60 RTS (No Aluminum Included)

Description

SOMFY BARRIER Levixo 60 24V RTS UNIT CENTRAL FOR ARM UP TO 6m

As an access control element, the electromechanical barrier works perfectly well any guarded car parks, at universities, offices, communities residential and other industrial facilities.
The design of the barrier makes it suitable for intensive work and guarantees 2000 cycles a day.

Levixo 60 has been adapted to passes with a width of 6 meters.
It is recommended to install a barrier arm support (optional) to ensure longer period of its operation.

The Levixo 60 central unit allows you to install an arm with a maximum 6m long. The 24V motor with a power of 300W has a torque of 260Nm. It has mechanical and electronic limit stops for safe and accurate operation and independent fuses to protect the control board.
Quick opening and closing (3-9 seconds) is undoubtedly a great advantage of the unit central, which gives 346 cycles / hour with intensive use. Thanks adjustable acceleration and deceleration, the barrier is in full control barrier speed.

User security

• Built-in obstacle detection thanks to encoder technology
• Adjustable final closing brake
• Full control of the barrier forces with adjustable opening moments and shutdown
• Orange lamp with 2 second warning

TECHNICAL DATA

• Power supply: 230 V
• Voltage: 24V
• Power input: 300 W
• Max. torque: 260 Nm
• Opening time: 3-9 s
• Number of starts per day: 2000
• Accessories power supply: 24V / 0.5A
• Number of remote controls that can be stored in the devicea: max 128 channels
• RTS remote control frequency: 433.42Mhz
• Operating temperature: -20 ° C + 55 ° C
• Protection class: IP54
